US Motors Nidec Neptune Square Flange Variable Speed Pump Motor 2.25HP 230V 48Y | NPTQ225

Description

The Neptune™ variable speed pool pump motor is a premium efficient product that includes a fully integrated motor, control and user interface (UI). This U.S. MOTORS® product gives you programming flexibility and speed range capability. It is also designed to communicate and operate with a variety of external system controllers in addition to the onboard UI.

Features and Benefits:

• Efficiency is 80%
• Sealed ball bearings
• Low temperature monitor. The motor, if set to do so, will automatically turn on during cold temperatures to keep the water moving which helps prevent pipe damage.
• Capability to set up to seven daily schedules
• Adjustable priming time and speed
• Menu keypad lockout feature
• Fully integrated product for simple drop-in installation with no complex motor and control wiring. Simply connect your power supply!
• For more capabilities, see Installation & Operation Manual below.

Specifications

• Total Horsepower: 2.25
• RPM: 600-3450
• Voltage: 230
• Frequency: 60/60
• SF Amps: 9.5
• System Efficiency: 81%
• Power Factor Corrected? Yes
• Catalog Number: NPTQ225
• Motor Frame: 48Y
• Length Less Shaft: 10.98″
• Weight (lbs): 35
• Speed: Variable
• Flange: Square
• Category: S

Installation & Operation Manual (PDF)
