Ultimax Impeller 1.5hp, (Green/Blue/Red/Blue) 1212227

Sale!
Ultimax Impeller 1.5hp, (Green/Blue/Red/Blue) 1212227

Ultimax Impeller 1.5hp, (Green/Blue/Red/Blue) 1212227

Original price was: $17.14.Current price is: $9.64.

78 in stock

SKU: 1212227 Category:

Description

Vico/Balboa Ultimax Impeller 1.5hp (model 1212227) is a closed-face replacement part for the Ultimax spa pump wet end. Designed for reliability, it is intended for use with 1.5 hp or larger thru-bolt motors to maintain proper pump performance and flow for spa circulation.

Key specifications: Impeller type — Closed Face; Diameter OD — 3-13/16 in; Vane width — 1/2 in; Eye diameter OD — 2-1/4 in; Eye length — 3/8 in; Impeller width OD — 1 in; Shaft length — 2 in; Shaft diameter OD — 11/16 in; Seal seat diameter OD — 1-5/16 in; Seal seat depth — 5/16 in. Shaft seal is sold separately as PS-201.

Installation notes: due to the shaft length, you may need to remove the water slinger or shorten the impeller shaft to ensure proper mating with the wet end. In some cases, a light seal lubricant helps install the seal onto the shaft when using compatible shaft seals.

Impeller Type Closed Face
Impeller Diameter OD 3-13/16″
Vane Width ID 1/2″
Eye Diameter OD 2-1/4″
Eye Length 3/8″
Impeller Width OD 1″
Seal Seat Depth 5/16″
Shaft Length 2″
Shaft Diameter OD 11/16″
Seal Seat Diameter OD 1-5/16″
Manufacturer Vico/Balboa
Pump Application Ultimax
