Century Replacement Motors – E-Plus, Square Flange, Threaded Shaft, 1.5 HP, 208-230 Volt – B2842

Sale!
Century Replacement Motors – E-Plus, Square Flange, Threaded Shaft, 1.5 HP, 208-230 Volt – B2842

Century Replacement Motors – E-Plus, Square Flange, Threaded Shaft, 1.5 HP, 208-230 Volt – B2842

Original price was: $86.18.Current price is: $60.70.

17 in stock

SKU: 26-2048 Category:

Description

Century Replacement Motors – E-Plus, Square Flange, Threaded Shaft, 1.5 HP, 230 Volt – B2842

Features
  • Open & Accessible Terminal Board & Wiring Compartment
  • Voltage Change Device
  • Sealed Ball Bearings
  • 50°C Ambient
  • Stainless Steel Shaft
  • UL 1081 Design
  • Switchless
  • Threaded Shaft
  • Permanent Split Capacitor
  • Open Dripproof
General Specifications
Model : B2842 Catalog No : B2842
Part Description : MODEL-CFHP-56FR Category : Induction Motors
Stock : Yes
Nameplate Specifications
Output HP : 1.5 Hp Output KW : 1.1 kW
Frequency : 60 Hz Voltage : 208-230 V
Current : SF 9.6-8.8 A Speed : 3450 rpm
Service Factor : 1.47 Phase : 1
Duty : Continuous Insulation Class : F
Frame : Y56Y Enclosure : Drip Proof
Overload Protector : Thermally Protected Ambient Temperature : 50 °C
UL : Recognized CSA : Y
Technical Specifications
Electrical Type : Permanent Split Capacitor, Single Or Dual Voltage Poles : 2
Rotation : Counterclockwise Pump End Mounting : Round
Motor Orientation : Horizontal Drive End Bearing : BALL
Opp Drive End Bearing : BALL Frame Material : Rolled Steel
Shaft Type : Threaded Overall Length : 13.90 in
Frame Length : 9.50 in Shaft Diameter : 0.625 in
Shaft Extension : 0.91 in UPC : 786674012210
Weight : 35.00 LB

Additional Information

Century Product Catalog

Warranty
